What does an ignition condenser do. The small engine condenser stores a high voltage charge. The condenser is attached to the system by breaker points. What does an ignition condenser do. The current from the ignition flows through the contacts and sends the voltage to the spark plugs which ignite the fuel. An ignition condenser is a capacitor that is designed to hold a small amount of current inside the engines ignition system. Basically the function of a condenser in a coil ignition circuit is to reduce the spark at the contact points as they open in the distributor and thus minimise burning and pitting of the points.

It holds the energy briefly until the points are closed again and then releases it back into the circuit where it flows through the points until they open again.

How do you test a small engine condenser. How to Test a Condenser in a Small Engine Remove the condenser from the engine. The small engine condenser stores a high voltage charge. The condenser absorbs the energy and prevents arcing between the points each time they open. The condenser and distributor rotate so that the points open and close continuously. The condenser absorbs the energy and prevents arcing between the points each time they open.

Ignition Condensers Contact Sets Distributor Caps And Rotors

What does a condenser do in an ignition system. What does an ignition condenser do. Do not use auto ranging as it is unreliable with a magneto. The spark plug wires also called ignition wires are insulated wires that carry the power to the spark plugs so that the spark plugs can finally create the spark that causes combustion.

A condenser is part of the ignition system used on most small engines. Arcing is caused by the effect of self induction in the coil as the points interrupt the flow of current. The condenser is a small electrical device connected across the contact-breaker points in the distributor.

By absorbing some of the charge the condenser allows the two contact points time to move away from. In a Kettering ignition the points are susceptible to arcing when they begin to open. The condenser in a Kettering inductive discharge ignition system with mechanical breaker points is merely a snubber.

The capacitor and coil do form a tank of sorts in a CDI system. Things is a car wont run without a condenser and it is not because the points instantly arc so badly that they wont function anymore. The spark plug consists of an insulated ceramic body with a conductive metal central core at the center.

Basically the function of a condenser in a coil ignition circuit is to reduce the spark at the contact points as they open in the distributor and thus minimise burning and pitting of the points. The condenser and distributor rotate so that the points open and close continuously. Condenser with its leads removed from the baseplate.

One is to shunt the current which because of the collapsing primary coil sides magnetic field wants to continue to flow and would otherwise arc and quickly ruin the points. The condenser gives the current a place to go when the points are in the open position. Two metal plates placed near each other and separated by insulating material such as paper.

Switch the volt ohmmeter to the ohms position. Instantaneously when the points open separate current flow stops through the primary windings of the ignition coil.
